M22759/29系列航空导线

作者：admin 来源： 日期：2015/10/14 15:35:40



MIL-W-22759/29 | SAE AS22759/29

MIL-W-22759/29 Wire

SAE AS22729

MIL-Spec Wire

mil-w-22759|SAE as22759/29

mil-w-22759/29线

SAEas22729

军用规格钢丝

mil-w-22759/29线（m22759/29线）构成：

导体：镍包铜

绝缘：挤压聚四氟乙烯

外套：聚酰亚胺涂层

mil-w-22759/29线（m22759/29线）指标：

额定电压：600伏

温度等级：260°

MIL-W-22759/29 | SAE AS22759/29

MIL-W-22759/29 Wire

SAE AS22729

MIL-Spec Wire



MIL-W-22759/29 Wire (M22759/29 Wire) Construction:



Conductor: Nickel coated copper

Insulation: Extruded PTFE

Jacket: Polyimide coating

MIL-W-22759/29 Wire (M22759/29 Wire) Ratings:



Voltage Rating: 600 Volts

Temperature Rating: 260°C

MIL-W-22759/29 Wire (M22759/29 Wire) Construction:



Conductor: Nickel coated copper

Insulation: Extruded PTFE

Jacket: Polyimide coating

MIL-W-22759/29 Wire (M22759/29 Wire) Ratings:



Voltage Rating: 600 Volts

Temperature Rating: 260°C

MIL-W-22759/32 (M22759/32) | SAE AS22759/32



 Finished Wire

Mil-Spec #           AWG  Stranding Min O.D. (in)   Max O.D. (in)  />

M22759/29-30-*   30     7/38        0.022           0.026           0.66

M22759/29-28-*   28     7/36        0.027           0.029           0.91

M22759/29-26-*   26    19/38       0.032           0.034           1.4

M22759/29-24-*   24    19/36       0.037           0.039           2.0

M22759/29-22-*   22    19/34       0.041           0.045           2.8

M22759/29-20-*   20    19/32       0.048           0.052           4.3

M22759/29-18-*   18    19/30       0.058           0.062           6.5

M22759/29-16-*   16    19/29       0.066           0.070           8.3

M22759/29-14-*   14    19/27       0.082           0.088          13.0

M22759/29-12-*   12    37/28       0.100           0.106          19.7

The asterisks in the above table shall be replaced by color code designators in accordance with MIL-STD-681.

0 - Black, 1 - Brown, 2 - Red, 3 - Orange, 4 - Yellow, 5 - Green, 6 - Blue, 7 - Violet, 8 - Gray, 9 - White

Example: Size 20, white - M22759/29-20-9; white with orange stripe -

M22759/29-20-93.



PART NUMBER AWG Conductor Stranding Approx LBS/MFT min O.D. (in) Max O.D. (in) Cond. Material Max. Temp Voltage
M22759/29-28-0 28 7/36 1.37 0.032 0.036 Nickel coated copper 260°C 600
M22759/29-28-1 28 7/36 1.37 0.032 0.036 Nickel coated copper 260°C 600
M22759/29-28-2 28 7/36 1.37 0.032 0.036 Nickel coated copper 260°C 600
M22759/29-28-3 28 7/36 1.37 0.032 0.036 Nickel coated copper 260°C 600
M22759/29-28-4 28 7/36 1.37 0.032 0.036 Nickel coated copper 260°C 600
M22759/29-28-5 28 7/36 1.37 0.032 0.036 Nickel coated copper 260°C 600
M22759/29-28-6 28 7/36 1.37 0.032 0.036 Nickel coated copper 260°C 600
M22759/29-28-7 28 7/36 1.37 0.032 0.036 Nickel coated copper 260°C 600
M22759/29-28-8 28 7/36 1.37 0.032 0.036 Nickel coated copper 260°C 600
M22759/29-28-9 28 7/36 1.37 0.032 0.036 Nickel coated copper 260°C 600
M22759/29-26-0 26 19/38 1.99 0.037 0.041 Nickel coated copper 260°C 600
M22759/29-26-1 26 19/38 1.99 0.037 0.041 Nickel coated copper 260°C 600
M22759/29-26-2 26 19/38 1.99 0.037 0.041 Nickel coated copper 260°C 600
M22759/29-26-3 26 19/38 1.99 0.037 0.041 Nickel coated copper 260°C 600
M22759/29-26-4 26 19/38 1.99 0.037 0.041 Nickel coated copper 260°C 600
M22759/29-26-5 26 19/38 1.99 0.037 0.041 Nickel coated copper 260°C 600
M22759/29-26-6 26 19/38 1.99 0.037 0.041 Nickel coated copper 260°C 600
M22759/29-26-7 26 19/38 1.99 0.037 0.041 Nickel coated copper 260°C 600
M22759/29-26-8 26 19/38 1.99 0.037 0.041 Nickel coated copper 260°C 600
M22759/29-26-9 26 19/38 1.99 0.037 0.041 Nickel coated copper 260°C 600
M22759/29-24-0 24 19/36 2.73 0.042 0.046 Nickel coated copper 260°C 600
M22759/29-24-1 24 19/36 2.73 0.042 0.046 Nickel coated copper 260°C 600
M22759/29-24-2 24 19/36 2.73 0.042 0.046 Nickel coated copper 260°C 600
M22759/29-24-3 24 19/36 2.73 0.042 0.046 Nickel coated copper 260°C 600
M22759/29-24-4 24 19/36 2.73 0.042 0.046 Nickel coated copper 260°C 600
M22759/29-24-5 24 19/36 2.73 0.042 0.046 Nickel coated copper 260°C 600
M22759/29-24-6 24 19/36 2.73 0.042 0.046 Nickel coated copper 260°C 600
M22759/29-24-7 24 19/36 2.73 0.042 0.046 Nickel coated copper 260°C 600
M22759/29-24-8 24 19/36 2.73 0.042 0.046 Nickel coated copper 260°C 600
M22759/29-24-9 24 19/36 2.73 0.042 0.046 Nickel coated copper 260°C 600
m22759/29-22-0 22 19/34 3.77 0.048 0.052 Nickel coated copper 260°C 600
m22759/29-22-1 22 19/34 3.77 0.048 0.052 Nickel coated copper 260°C 600
m22759/29-22-2 22 19/34 3.77 0.048 0.052 Nickel coated copper 260°C 600
m22759/29-22-3 22 19/34 3.77 0.048 0.052 Nickel coated copper 260°C 600
m22759/29-22-4 22 19/34 3.77 0.048 0.052 Nickel coated copper 260°C 600
m22759/29-22-5 22 19/34 3.77 0.048 0.052 Nickel coated copper 260°C 600
m22759/29-22-6 22 19/34 3.77 0.048 0.052 Nickel coated copper 260°C 600
m22759/29-22-7 22 19/34 3.77 0.048 0.052 Nickel coated copper 260°C 600
m22759/29-22-8 22 19/34 3.77 0.048 0.052 Nickel coated copper 260°C 600
m22759/29-22-9 22 19/34 3.77 0.048 0.052 Nickel coated copper 260°C 600
m22759/29-20-0 20 19/32 5.55 0.057 0.061 Nickel coated copper 260°C 600
m22759/29-20-1 20 19/32 5.55 0.057 0.061 Nickel coated copper 260°C 600
m22759/29-20-2 20 19/32 5.55 0.057 0.061 Nickel coated copper 260°C 600
m22759/29-20-3 20 19/32 5.55 0.057 0.061 Nickel coated copper 260°C 600
m22759/29-20-4 20 19/32 5.55 0.057 0.061 Nickel coated copper 260°C 600
m22759/29-20-5 20 19/32 5.55 0.057 0.061 Nickel coated copper 260°C 600
m22759/29-20-6 20 19/32 5.55 0.057 0.061 Nickel coated copper 260°C 600
m22759/29-20-7 20 19/32 5.55 0.057 0.061 Nickel coated copper 260°C 600
m22759/29-20-8 20 19/32 5.55 0.057 0.061 Nickel coated copper 260°C 600
m22759/29-20-9 20 19/32 5.55 0.057 0.061 Nickel coated copper 260°C 600
M22759/29-18-0 18 19/30 8.15 0.067 0.071 Nickel coated copper 260°C 600
M22759/29-18-1 18 19/30 8.15 0.067 0.071 Nickel coated copper 260°C 600
M22759/29-18-2 18 19/30 8.15 0.067 0.071 Nickel coated copper 260°C 600
M22759/29-18-3 18 19/30 8.15 0.067 0.071 Nickel coated copper 260°C 600
M22759/29-18-4 18 19/30 8.15 0.067 0.071 Nickel coated copper 260°C 600
M22759/29-18-5 18 19/30 8.15 0.067 0.071 Nickel coated copper 260°C 600
M22759/29-18-6 18 19/30 8.15 0.067 0.071 Nickel coated copper 260°C 600
M22759/29-18-7 18 19/30 8.15 0.067 0.071 Nickel coated copper 260°C 600
M22759/29-18-8 18 19/30 8.15 0.067 0.071 Nickel coated copper 260°C 600
M22759/29-18-9 18 19/30 8.15 0.067 0.071 Nickel coated copper 260°C 600
M22759/29-16-0 16 19/29 10.1 0.073 0.079 Nickel coated copper 260°C 600
M22759/29-16-1 16 19/29 10.1 0.073 0.079 Nickel coated copper 260°C 600
M22759/29-16-2 16 19/29 10.1 0.073 0.079 Nickel coated copper 260°C 600
M22759/29-16-3 16 19/29 10.1 0.073 0.079 Nickel coated copper 260°C 600
M22759/29-16-4 16 19/29 10.1 0.073 0.079 Nickel coated copper 260°C 600
M22759/29-16-5 16 19/29 10.1 0.073 0.079 Nickel coated copper 260°C 600
M22759/29-16-6 16 19/29 10.1 0.073 0.079 Nickel coated copper 260°C 600
M22759/29-16-7 16 19/29 10.1 0.073 0.079 Nickel coated copper 260°C 600
M22759/29-16-8 16 19/29 10.1 0.073 0.079 Nickel coated copper 260°C 600
M22759/29-16-9 16 19/29 10.1 0.073 0.079 Nickel coated copper 260°C 600
M22759/29-14-0 14 19/27 15.3 0.088 0.094 Nickel coated copper 260°C 600
M22759/29-14-1 14 19/27 15.3 0.088 0.094 Nickel coated copper 260°C 600
M22759/29-14-2 14 19/27 15.3 0.088 0.094 Nickel coated copper 260°C 600
M22759/29-14-3 14 19/27 15.3 0.088 0.094 Nickel coated copper 260°C 600
M22759/29-14-4 14 19/27 15.3 0.088 0.094 Nickel coated copper 260°C 600
M22759/29-14-5 14 19/27 15.3 0.088 0.094 Nickel coated copper 260°C 600
M22759/29-14-6 14 19/27 15.3 0.088 0.094 Nickel coated copper 260°C 600
M22759/29-14-7 14 19/27 15.3 0.088 0.094 Nickel coated copper 260°C 600
M22759/29-14-8 14 19/27 15.3 0.088 0.094 Nickel coated copper 260°C 600
M22759/29-14-9 14 19/27 15.3 0.088 0.094 Nickel coated copper 260°C 600
M22759/29-12-0 12 19/25 23.6 0.108 0.114 Nickel coated copper 260°C 600
M22759/29-12-1 12 19/25 23.6 0.108 0.114 Nickel coated copper 260°C 600
M22759/29-12-2 12 19/25 23.6 0.108 0.114 Nickel coated copper 260°C 600
M22759/29-12-3 12 19/25 23.6 0.108 0.114 Nickel coated copper 260°C 600
M22759/29-12-4 12 19/25 23.6 0.108 0.114 Nickel coated copper 260°C 600
M22759/29-12-5 12 19/25 23.6 0.108 0.114 Nickel coated copper 260°C 600
M22759/29-12-6 12 19/25 23.6 0.108 0.114 Nickel coated copper 260°C 600
M22759/29-12-7 12 19/25 23.6 0.108 0.114 Nickel coated copper 260°C 600
M22759/29-12-8 12 19/25 23.6 0.108 0.114 Nickel coated copper 260°C 600
M22759/29-12-9 12 19/25 23.6 0.108 0.114 Nickel coated copper 260°C 600
M22759/29-10-0 10 37/26 36.1 0.137 0.143 Nickel coated copper 260°C 600
M22759/29-10-1 10 37/26 36.1 0.137 0.143 Nickel coated copper 260°C 600
M22759/29-10-2 10 37/26 36.1 0.137 0.143 Nickel coated copper 260°C 600
M22759/29-10-3 10 37/26 36.1 0.137 0.143 Nickel coated copper 260°C 600
M22759/29-10-4 10 37/26 36.1 0.137 0.143 Nickel coated copper 260°C 600
M22759/29-10-5 10 37/26 36.1 0.137 0.143 Nickel coated copper 260°C 600
M22759/29-10-6 10 37/26 36.1 0.137 0.143 Nickel coated copper 260°C 600
M22759/29-10-7 10 37/26 36.1 0.137 0.143 Nickel coated copper 260°C 600
M22759/29-10-8 10 37/26 36.1 0.137 0.143 Nickel coated copper 260°C 600
M22759/29-10-9 10 37/26 36.1 0.137 0.143 Nickel coated copper 260°C 600

河南三博电子是一家专业M22759/29系列航空导线的供应商，我公司经营M22759/29系列航空导线产品多年，质量口碑可靠。如果您有更多的M22759/29系列航空导线价格问题，欢迎您联系我们厂家
