MIL-W-22759/33 (M22759/33) | SAE AS22759/33

mil-w-22759/33

SAEas22759/33

标准墙

军用规格导线

m22759/33构造：

导体：镀银高强度铜合金导线

绝缘材料：氟聚合物交联改性四氟乙烯单绝缘

m22759/33额定值：

额定电压：600伏

温度等级：200°（392°华氏）

应用：

高温，重量轻航空应用，增加机械强度和耐磨性是必需的

特点：

产品描述：

高链镀银高强度铜合金导线

交联改性四氟乙烯绝缘（单墙），按照mil-std-681颜色编码

额定温度：

200°

额定电压：

600伏

MIL-W-22759/33

SAE AS22759/33

Standard Wall

MIL Spec Wire



M22759/33 Construction:



Conductor: Silver Coated High Strength Copper Alloy Conductor

Insulation: Fluoropolymer Cross-linked Modified ETFE Single Insulation

M22759/33 Ratings:



Voltage Rating: 600 Volts

Temperature Rating: 200°C (392°F)



APPLICATIONS:



High temperature, light weight aerospace applications where increased mechanical strength and abrasion resistance is required

CHARCACTERISTICS:



PRODUCT DESCRIPTION:



Stranded silver coated high strength copper alloy conductor

Cross-linked modified ETFE insulation (single wall), color coded in accordance with MIL-STD-681

TEMPERATURE RATING:



200°C

VOLTAGE RATING:



600 volts

军规＃ AWG 绞合 最小外径 最大外径 重量



M22759/33-30-* 30 7/38         0.022 0.026 .66

M22759/33-28-* 28 7/36         0.025 0.029 .91

M22759/33-26-* 26 19/38 0.030 0.034 1.4

M22759/33-24-* 24 19/36 0.035 0.039 2.0

M22759/33-22-* 22 19/34 0.041 0.045 2.9

M22759/33-20-* 20 19/32 0.048 0.052 4.4

The asterisks in the above table shall be replaced by color code designators in accordance with MIL-STD-681.

0 - Black, 1 - Brown, 2 - Red, 3 - Orange, 4 - Yellow, 5 - Green, 6 - Blue, 7 - Violet, 8 - Gray, 9 - White

Example: Size 20, white - M22759/33-20-9; white with orange stripe -

M22759/33-20-93.



PART NUMBER	AWG	Conductor Stranding	Approx LBS/MFT	min O.D. (in)	Max O.D. (in)	Cond. Material	Max. Temp	Voltage
M22759/33-30-0	30	7/38	0.66	0.022	0.026	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-30-1	30	7/38	0.66	0.022	0.026	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-30-2	30	7/38	0.66	0.022	0.026	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-30-3	30	7/38	0.66	0.022	0.026	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-30-4	30	7/38	0.66	0.022	0.026	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-30-5	30	7/38	0.66	0.022	0.026	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-30-6	30	7/38	0.66	0.022	0.026	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-30-7	30	7/38	0.66	0.022	0.026	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-30-8	30	7/38	0.66	0.022	0.026	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-30-9	30	7/38	0.66	0.022	0.026	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-28-0	28	7/36	0.91	0.025	0.029	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-28-1	28	7/36	0.91	0.025	0.029	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-28-2	28	7/36	0.91	0.025	0.029	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-28-3	28	7/36	0.91	0.025	0.029	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-28-4	28	7/36	0.91	0.025	0.029	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-28-5	28	7/36	0.91	0.025	0.029	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-28-6	28	7/36	0.91	0.025	0.029	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-28-7	28	7/36	0.91	0.025	0.029	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-28-8	28	7/36	0.91	0.025	0.029	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-28-9	28	7/36	0.91	0.025	0.029	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-26-0	26	19/38	1.4	0.03	0.034	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-26-1	26	19/38	1.4	0.03	0.034	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-26-2	26	19/38	1.4	0.03	0.034	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-26-3	26	19/38	1.4	0.03	0.034	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-26-4	26	19/38	1.4	0.03	0.034	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-26-5	26	19/38	1.4	0.03	0.034	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-26-6	26	19/38	1.4	0.03	0.034	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-26-7	26	19/38	1.4	0.03	0.034	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-26-8	26	19/38	1.4	0.03	0.034	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-26-9	26	19/38	1.4	0.03	0.034	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-24-0	24	19/36	2	0.035	0.039	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-24-1	24	19/36	2	0.035	0.039	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-24-2	24	19/36	2	0.035	0.039	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-24-3	24	19/36	2	0.035	0.039	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-24-4	24	19/36	2	0.035	0.039	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-24-5	24	19/36	2	0.035	0.039	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-24-6	24	19/36	2	0.035	0.039	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-24-7	24	19/36	2	0.035	0.039	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-24-8	24	19/36	2	0.035	0.039	Silver Coated High Strength Copper Alloy Conductor	200°C	600
M22759/33-24-9	24	19/36	2	0.035	0.039	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-22-0	22	19/34	2.9	0.041	0.045	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-22-1	22	19/34	2.9	0.041	0.045	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-22-2	22	19/34	2.9	0.041	0.045	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-22-3	22	19/34	2.9	0.041	0.045	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-22-4	22	19/34	2.9	0.041	0.045	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-22-5	22	19/34	2.9	0.041	0.045	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-22-6	22	19/34	2.9	0.041	0.045	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-22-7	22	19/34	2.9	0.041	0.045	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-22-8	22	19/34	2.9	0.041	0.045	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-22-9	22	19/34	2.9	0.041	0.045	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-20-0	20	19/32	4.4	0.048	0.052	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-20-1	20	19/32	4.4	0.048	0.052	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-20-2	20	19/32	4.4	0.048	0.052	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-20-3	20	19/32	4.4	0.048	0.052	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-20-4	20	19/32	4.4	0.048	0.052	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-20-5	20	19/32	4.4	0.048	0.052	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-20-6	20	19/32	4.4	0.048	0.052	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-20-7	20	19/32	4.4	0.048	0.052	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-20-8	20	19/32	4.4	0.048	0.052	Silver Coated High Strength Copper Alloy Conductor	200°C	600
m22759/33-20-9	20	19/32	4.4	0.048	0.052	Silver Coated High Strength Copper Alloy Conductor	200°C	600

河南三博电子是一家专业M22759/33航空线缆的供应商，我公司经营M22759/33航空线缆产品多年，质量口碑可靠。如果您有更多的M22759/33航空线缆价格问题，欢迎您联系我们厂家
