MIL-W-22759/34 (M22759/34) | SAE AS22759/34

作者：admin 来源： 日期：2015/10/16 13:02:06

M22759/34|SAE AS22759/34导线河南三博电子科技有限公司供应

应用：
高温机身和航空电子线束应用
特性：
产品描述：
镀锡铜导体
交联改性四氟乙烯绝缘（双壁），按照mil-std-681颜色编码
线规尺寸大于2的有深绿色，有芳香族聚酰胺编织5D的颜色代码标志
额定温度：
150°
额定电压：

600伏


Mil-Spec #           AWG    Stranding  Min O.D. (in)  MaxO.D. (in)   />

M22759/34-24-*   24       19/36        0.043          0.047              2.3

M22759/34-22-*   22       19/34        0.048          0.052              3.2

M22759/34-20-*   20       19/32        0.056          0.060              4.7

M22759/34-18-*   18       19/30        0.067          0.073              7.2

M22759/34-16-*   16       19/29        0.074          0.080               9.0

M22759/34-14-*   14       19/27        0.091          0.097              13.8

M22759/34-12-*   12       37/28        0.108          0.114               20.5

M22759/34-10-*   10       37/26        0.130          0.138               32.4

M22759/34-8-*      8      133/29        0.177          0.203               60.3

M22759/34-6-*      6      133/27        0.231          0.251               94.5

M22759/34-4-*      4      133/25        0.300          0.320                150

M22759/34-2-*     2     665/30 0.389   0.421            239

M22759/34-1-*     1     817/30 0.429   0.461            290

M22759/34-01-*  1/0   1045/30 0.469    0.501            377

M22759/34-02-*  2/0   1330/30 0.529    0.561            487

The asterisks in the above table shall be replaced by color code designators in accordance with MIL-STD-681.

0 - Black, 1 - Brown, 2 - Red, 3 - Orange, 4 - Yellow, 5 - Green, 6 - Blue, 7 - Violet, 8 - Gray, 9 - White

Example: Size 20, white - M22759/34-20-9; white with orange stripe -

M22759/34-20-93.

mil-w-22759/34线

SAE as22759/34

标准墙

军用规格钢丝

mil-w-22759/34线（m22759/34线）构建：

导体：镀锡铜

绝缘材料：氟聚合物交联改性和双重绝缘

护套：xl-etfe

编织：处理过的芳香聚酰胺2号

mil-w-22759/ 34线（m22759/4线）参数：

额定电压：600伏

温度等级：150



PART NUMBER AWG Conductor Stranding Approx LBS/MFT min O.D. (in) Max O.D. (in) Cond. Material Max. Temp Voltage
M22759/34-24-0 24 19/36 2.3 0.043 0.047 Tinned Copper 150°C 600
M22759/34-24-1 24 19/36 2.3 0.043 0.047 Tinned Copper 150°C 600
M22759/34-24-2 24 19/36 2.3 0.043 0.047 Tinned Copper 150°C 600
M22759/34-24-3 24 19/36 2.3 0.043 0.047 Tinned Copper 150°C 600
M22759/34-24-4 24 19/36 2.3 0.043 0.047 Tinned Copper 150°C 600
M22759/34-24-5 24 19/36 2.3 0.043 0.047 Tinned Copper 150°C 600
M22759/34-24-6 24 19/36 2.3 0.043 0.047 Tinned Copper 150°C 600
M22759/34-24-7 24 19/36 2.3 0.043 0.047 Tinned Copper 150°C 600
M22759/34-24-8 24 19/36 2.3 0.043 0.047 Tinned Copper 150°C 600
M22759/34-24-9 24 19/36 2.3 0.043 0.047 Tinned Copper 150°C 600
m22759/34-22-0 22 19/34 3.2 0.048 0.052 Tinned Copper 150°C 600
m22759/34-22-1 22 19/34 3.2 0.048 0.052 Tinned Copper 150°C 600
m22759/34-22-2 22 19/34 3.2 0.048 0.052 Tinned Copper 150°C 600
m22759/34-22-3 22 19/34 3.2 0.048 0.052 Tinned Copper 150°C 600
m22759/34-22-4 22 19/34 3.2 0.048 0.052 Tinned Copper 150°C 600
m22759/34-22-5 22 19/34 3.2 0.048 0.052 Tinned Copper 150°C 600
m22759/34-22-6 22 19/34 3.2 0.048 0.052 Tinned Copper 150°C 600
m22759/34-22-7 22 19/34 3.2 0.048 0.052 Tinned Copper 150°C 600
m22759/34-22-8 22 19/34 3.2 0.048 0.052 Tinned Copper 150°C 600
m22759/34-22-9 22 19/34 3.2 0.048 0.052 Tinned Copper 150°C 600
m22759/34-20-0 20 19/32 4.7 0.056 0.06 Tinned Copper 150°C 600
m22759/34-20-1 20 19/32 4.7 0.056 0.06 Tinned Copper 150°C 600
m22759/34-20-2 20 19/32 4.7 0.056 0.06 Tinned Copper 150°C 600
m22759/34-20-3 20 19/32 4.7 0.056 0.06 Tinned Copper 150°C 600
m22759/34-20-4 20 19/32 4.7 0.056 0.06 Tinned Copper 150°C 600
m22759/34-20-5 20 19/32 4.7 0.056 0.06 Tinned Copper 150°C 600
m22759/34-20-6 20 19/32 4.7 0.056 0.06 Tinned Copper 150°C 600
m22759/34-20-7 20 19/32 4.7 0.056 0.06 Tinned Copper 150°C 600
m22759/34-20-8 20 19/32 4.7 0.056 0.06 Tinned Copper 150°C 600
m22759/34-20-9 20 19/32 4.7 0.056 0.06 Tinned Copper 150°C 600
M22759/34-18-0 18 19/30 7.2 0.067 0.073 Tinned Copper 150°C 600
M22759/34-18-1 18 19/30 7.2 0.067 0.073 Tinned Copper 150°C 600
M22759/34-18-2 18 19/30 7.2 0.067 0.073 Tinned Copper 150°C 600
M22759/34-18-3 18 19/30 7.2 0.067 0.073 Tinned Copper 150°C 600
M22759/34-18-4 18 19/30 7.2 0.067 0.073 Tinned Copper 150°C 600
M22759/34-18-5 18 19/30 7.2 0.067 0.073 Tinned Copper 150°C 600
M22759/34-18-6 18 19/30 7.2 0.067 0.073 Tinned Copper 150°C 600
M22759/34-18-7 18 19/30 7.2 0.067 0.073 Tinned Copper 150°C 600
M22759/34-18-8 18 19/30 7.2 0.067 0.073 Tinned Copper 150°C 600
M22759/34-18-9 18 19/30 7.2 0.067 0.073 Tinned Copper 150°C 600
M22759/34-16-0 16 19/29 9 0.074 0.08 Tinned Copper 150°C 600
M22759/34-16-1 16 19/29 9 0.074 0.08 Tinned Copper 150°C 600
M22759/34-16-2 16 19/29 9 0.074 0.08 Tinned Copper 150°C 600
M22759/34-16-3 16 19/29 9 0.074 0.08 Tinned Copper 150°C 600
M22759/34-16-4 16 19/29 9 0.074 0.08 Tinned Copper 150°C 600
M22759/34-16-5 16 19/29 9 0.074 0.08 Tinned Copper 150°C 600
M22759/34-16-6 16 19/29 9 0.074 0.08 Tinned Copper 150°C 600
M22759/34-16-7 16 19/29 9 0.074 0.08 Tinned Copper 150°C 600
M22759/34-16-8 16 19/29 9 0.074 0.08 Tinned Copper 150°C 600
M22759/34-16-9 16 19/29 9 0.074 0.08 Tinned Copper 150°C 600
M22759/34-14-0 14 19/27 13.8 0.091 0.097 Tinned Copper 150°C 600
M22759/34-14-1 14 19/27 13.8 0.091 0.097 Tinned Copper 150°C 600
M22759/34-14-2 14 19/27 13.8 0.091 0.097 Tinned Copper 150°C 600
M22759/34-14-3 14 19/27 13.8 0.091 0.097 Tinned Copper 150°C 600
M22759/34-14-4 14 19/27 13.8 0.091 0.097 Tinned Copper 150°C 600
M22759/34-14-5 14 19/27 13.8 0.091 0.097 Tinned Copper 150°C 600
M22759/34-14-6 14 19/27 13.8 0.091 0.097 Tinned Copper 150°C 600
M22759/34-14-7 14 19/27 13.8 0.091 0.097 Tinned Copper 150°C 600
M22759/34-14-8 14 19/27 13.8 0.091 0.097 Tinned Copper 150°C 600
M22759/34-14-9 14 19/27 13.8 0.091 0.097 Tinned Copper 150°C 600
M22759/34-12-0 12 37/28 20.5 0.108 0.114 Tinned Copper 150°C 600
M22759/34-12-1 12 37/28 20.5 0.108 0.114 Tinned Copper 150°C 600
M22759/34-12-2 12 37/28 20.5 0.108 0.114 Tinned Copper 150°C 600
M22759/34-12-3 12 37/28 20.5 0.108 0.114 Tinned Copper 150°C 600
M22759/34-12-4 12 37/28 20.5 0.108 0.114 Tinned Copper 150°C 600
M22759/34-12-5 12 37/28 20.5 0.108 0.114 Tinned Copper 150°C 600
M22759/34-12-6 12 37/28 20.5 0.108 0.114 Tinned Copper 150°C 600
M22759/34-12-7 12 37/28 20.5 0.108 0.114 Tinned Copper 150°C 600
M22759/34-12-8 12 37/28 20.5 0.108 0.114 Tinned Copper 150°C 600
M22759/34-12-9 12 37/28 20.5 0.108 0.114 Tinned Copper 150°C 600
m22759/34-10-0 10 37/26 32.4 0.13 0.138 Tinned Copper 150°C 600
m22759/34-10-1 10 37/26 32.4 0.13 0.138 Tinned Copper 150°C 600
m22759/34-10-2 10 37/26 32.4 0.13 0.138 Tinned Copper 150°C 600
m22759/34-10-3 10 37/26 32.4 0.13 0.138 Tinned Copper 150°C 600
m22759/34-10-4 10 37/26 32.4 0.13 0.138 Tinned Copper 150°C 600
m22759/34-10-5 10 37/26 32.4 0.13 0.138 Tinned Copper 150°C 600
m22759/34-10-6 10 37/26 32.4 0.13 0.138 Tinned Copper 150°C 600
m22759/34-10-7 10 37/26 32.4 0.13 0.138 Tinned Copper 150°C 600
m22759/34-10-8 10 37/26 32.4 0.13 0.138 Tinned Copper 150°C 600
m22759/34-10-9 10 37/26 32.4 0.13 0.138 Tinned Copper 150°C 600
m22759/34-8-0 8 133/29 60.3 0.187 0.203 Tinned Copper 150°C 600
m22759/34-8-1 8 133/29 60.3 0.187 0.203 Tinned Copper 150°C 600
m22759/34-8-2 8 133/29 60.3 0.187 0.203 Tinned Copper 150°C 600
m22759/34-8-3 8 133/29 60.3 0.187 0.203 Tinned Copper 150°C 600
m22759/34-8-4 8 133/29 60.3 0.187 0.203 Tinned Copper 150°C 600
m22759/34-8-5 8 133/29 60.3 0.187 0.203 Tinned Copper 150°C 600
m22759/34-8-6 8 133/29 60.3 0.187 0.203 Tinned Copper 150°C 600
m22759/34-8-7 8 133/29 60.3 0.187 0.203 Tinned Copper 150°C 600
m22759/34-8-8 8 133/29 60.3 0.187 0.203 Tinned Copper 150°C 600
m22759/34-8-9 8 133/29 60.3 0.187 0.203 Tinned Copper 150°C 600
m22759/34-6-0 6 133/27 94.5 0.231 0.251 Tinned Copper 150°C 600
m22759/34-6-1 6 133/27 94.5 0.231 0.251 Tinned Copper 150°C 600
m22759/34-6-2 6 133/27 94.5 0.231 0.251 Tinned Copper 150°C 600
m22759/34-6-3 6 133/27 94.5 0.231 0.251 Tinned Copper 150°C 600
m22759/34-6-4 6 133/27 94.5 0.231 0.251 Tinned Copper 150°C 600
m22759/34-6-5 6 133/27 94.5 0.231 0.251 Tinned Copper 150°C 600
m22759/34-6-6 6 133/27 94.5 0.231 0.251 Tinned Copper 150°C 600
m22759/34-6-7 6 133/27 94.5 0.231 0.251 Tinned Copper 150°C 600
m22759/34-6-8 6 133/27 94.5 0.231 0.251 Tinned Copper 150°C 600
m22759/34-6-9 6 133/27 94.5 0.231 0.251 Tinned Copper 150°C 600
m22759/34-4-0 4 133/25 150 0.3 0.32 Tinned Copper 150°C 600
m22759/34-4-1 4 133/25 150 0.3 0.32 Tinned Copper 150°C 600
m22759/34-4-2 4 133/25 150 0.3 0.32 Tinned Copper 150°C 600
m22759/34-4-3 4 133/25 150 0.3 0.32 Tinned Copper 150°C 600
m22759/34-4-4 4 133/25 150 0.3 0.32 Tinned Copper 150°C 600
m22759/34-4-5 4 133/25 150 0.3 0.32 Tinned Copper 150°C 600
m22759/34-4-6 4 133/25 150 0.3 0.32 Tinned Copper 150°C 600
m22759/34-4-7 4 133/25 150 0.3 0.32 Tinned Copper 150°C 600
m22759/34-4-8 4 133/25 150 0.3 0.32 Tinned Copper 150°C 600
m22759/34-4-9 4 133/25 150 0.3 0.32 Tinned Copper 150°C 600
M22759/34-2-0 2 665/30 239 0.39 0.428 Tinned Copper 150°C 600
M22759/34-2-1 2 665/30 239 0.39 0.428 Tinned Copper 150°C 600
M22759/34-2-2 2 665/30 239 0.39 0.428 Tinned Copper 150°C 600
M22759/34-2-3 2 665/30 239 0.39 0.428 Tinned Copper 150°C 600
M22759/34-2-4 2 665/30 239 0.39 0.428 Tinned Copper 150°C 600
M22759/34-2-5 2 665/30 239 0.39 0.428 Tinned Copper 150°C 600
M22759/34-2-6 2 665/30 239 0.39 0.428 Tinned Copper 150°C 600
M22759/34-2-7 2 665/30 239 0.39 0.428 Tinned Copper 150°C 600
M22759/34-2-8 2 665/30 239 0.39 0.428 Tinned Copper 150°C 600
M22759/34-2-9 2 665/30 239 0.39 0.428 Tinned Copper 150°C 600
M22759/34-1-0 1 817/30 290 0.429 0.461 Tinned Copper 150°C 600
M22759/34-1-1 1 817/30 290 0.429 0.461 Tinned Copper 150°C 600
M22759/34-1-2 1 817/30 290 0.429 0.461 Tinned Copper 150°C 600
M22759/34-1-3 1 817/30 290 0.429 0.461 Tinned Copper 150°C 600
M22759/34-1-4 1 817/30 290 0.429 0.461 Tinned Copper 150°C 600
M22759/34-1-5 1 817/30 290 0.429 0.461 Tinned Copper 150°C 600
M22759/34-1-6 1 817/30 290 0.429 0.461 Tinned Copper 150°C 600
M22759/34-1-7 1 817/30 290 0.429 0.461 Tinned Copper 150°C 600
M22759/34-1-8 1 817/30 290 0.429 0.461 Tinned Copper 150°C 600
M22759/34-1-9 1 817/30 290 0.429 0.461 Tinned Copper 150°C 600
M22759/34-01-0 1/0 1045/30 377 0.469 0.501 Tinned Copper 150°C 600
M22759/34-01-1 1/0 1045/30 377 0.469 0.501 Tinned Copper 150°C 600
M22759/34-01-2 1/0 1045/30 377 0.469 0.501 Tinned Copper 150°C 600
M22759/34-01-3 1/0 1045/30 377 0.469 0.501 Tinned Copper 150°C 600
M22759/34-01-4 1/0 1045/30 377 0.469 0.501 Tinned Copper 150°C 600
M22759/34-01-5 1/0 1045/30 377 0.469 0.501 Tinned Copper 150°C 600
M22759/34-01-6 1/0 1045/30 377 0.469 0.501 Tinned Copper 150°C 600
M22759/34-01-7 1/0 1045/30 377 0.469 0.501 Tinned Copper 150°C 600
M22759/34-01-8 1/0 1045/30 377 0.469 0.501 Tinned Copper 150°C 600
M22759/34-01-9 1/0 1045/30 377 0.469 0.501 Tinned Copper 150°C 600
M22759/34-02-0 2/0 1330/30 487 0.529 0.561 Tinned Copper 150°C 600
M22759/34-02-1 2/0 1330/30 487 0.529 0.561 Tinned Copper 150°C 600
M22759/34-02-2 2/0 1330/30 487 0.529 0.561 Tinned Copper 150°C 600
M22759/34-02-3 2/0 1330/30 487 0.529 0.561 Tinned Copper 150°C 600
M22759/34-02-4 2/0 1330/30 487 0.529 0.561 Tinned Copper 150°C 600
M22759/34-02-5 2/0 1330/30 487 0.529 0.561 Tinned Copper 150°C 600
M22759/34-02-6 2/0 1330/30 487 0.529 0.561 Tinned Copper 150°C 600
M22759/34-02-7 2/0 1330/30 487 0.529 0.561 Tinned Copper 150°C 600
M22759/34-02-8 2/0 1330/30 487 0.529 0.561 Tinned Copper 150°C 600
M22759/34-02-9 2/0 1330/30 487 0.529 0.561 Tinned Copper 150°C 600

河南三博电子是一家专业MIL-W-22759/34 (M22759/34) | SAE AS22759/34的供应商，我公司经营MIL-W-22759/34 (M22759/34) | SAE AS22759/34产品多年，质量口碑可靠。如果您有更多的MIL-W-22759/34 (M22759/34) | SAE AS22759/34价格问题，欢迎您联系我们厂家

  • 上一篇：M22759/33航空线缆
  • 下一篇：(M22759/35)航空线[MIL-W-22759/35] | SAE AS22759/35

    • 其他信息

    Coryright 河南三博电子科技有限公司 版权所有

    公司地址：河南省郑州市中原区颖河路76号颖河港湾11栋2单元1004 地址：www.hnsanbo.com

    电话：0371-55365505 传真：0371-86257077 邮箱：hnsanbo@163.com 网站关键词:连接器-航空线缆-航空插头、航空线缆、军品连接器、军用操作工具,军用操作工具,集成电路,电源开关生产
