MIL-W-22759/44 (M22759/44) | SAE AS22759/44

作者：admin 来源： 日期：2015/10/22 20:28:12
SAE as22759/44
标准壁面
军用规格钢丝
m22759/44构造：
导体：镀银铜导体
绝缘材料：氟聚合物交联改性四氟乙烯单绝缘
m22759/44额定值：
额定电压：600伏
温度等级：200°（392°）


MIL-W-22759/44 (M22759/44) | SAE AS22759/44
Mil-Spec #       AWG    Stranding  Min O.D. (in)     MaxO.D. (in)    Nom.Lbs/Mft

M22759/44-28-* 28 7/36      0.025       0.029                   0.91
M22759/44-26-* 26 19/38 0.03       0.034                   1.4
M22759/44-24-* 24 19/36 0.035 0.039           2
M22759/44-22-* 22 19/34 0.041 0.045         2.8
M22759/44-20-* 20 19/32 0.048 0.052         4.3
M22759/44-18-* 18 19/30 0.058 0.062         6.5
M22759/44-16-* 16 19/29 0.066 0.07                 8.3
M22759/44-14-* 14 19/27 0.082 0.088         13
M22759/44-12-* 12 37/28 0.1        0.106                19.7

The asterisks in the above table shall be replaced by color code designators in accordance with MIL-STD-681.
0 - Black, 1 - Brown, 2 - Red, 3 - Orange, 4 - Yellow, 5 - Green, 6 - Blue, 7 - Violet, 8 - Gray, 9 - White
Example: Size 20, white - M22759/11-20-9; white with orange stripe -
M22759/11-20-93.

PART NUMBER AWG Conductor Stranding Approx LBS/MFT Max. Resistance @ 20°C OHMS/MFT Cond. Material Max. Temp Voltage
M22759/44/28-0 28 7/36 0.91 63.8 Silver Coated Copper Conductor 200°C 600
M22759/44/28-1 28 7/36 0.91 63.8 Silver Coated Copper Conductor 200°C 600
M22759/44/28-2 28 7/36 0.91 63.8 Silver Coated Copper Conductor 200°C 600
M22759/44/28-3 28 7/36 0.91 63.8 Silver Coated Copper Conductor 200°C 600
M22759/44/28-4 28 7/36 0.91 63.8 Silver Coated Copper Conductor 200°C 600
M22759/44/28-5 28 7/36 0.91 63.8 Silver Coated Copper Conductor 200°C 600
M22759/44/28-6 28 7/36 0.91 63.8 Silver Coated Copper Conductor 200°C 600
M22759/44/28-7 28 7/36 0.91 63.8 Silver Coated Copper Conductor 200°C 600
M22759/44/28-8 28 7/36 0.91 63.8 Silver Coated Copper Conductor 200°C 600
M22759/44/28-9 28 7/36 0.91 63.8 Silver Coated Copper Conductor 200°C 600
M22759/44/26-0 26 19/38 1.4 38.4 Silver Coated Copper Conductor 200°C 600
M22759/44/26-1 26 19/38 1.4 38.4 Silver Coated Copper Conductor 200°C 600
M22759/44/26-2 26 19/38 1.4 38.4 Silver Coated Copper Conductor 200°C 600
M22759/44/26-3 26 19/38 1.4 38.4 Silver Coated Copper Conductor 200°C 600
M22759/44/26-4 26 19/38 1.4 38.4 Silver Coated Copper Conductor 200°C 600
M22759/44/26-5 26 19/38 1.4 38.4 Silver Coated Copper Conductor 200°C 600
M22759/44/26-6 26 19/38 1.4 38.4 Silver Coated Copper Conductor 200°C 600
M22759/44/26-7 26 19/38 1.4 38.4 Silver Coated Copper Conductor 200°C 600
M22759/44/26-8 26 19/38 1.4 38.4 Silver Coated Copper Conductor 200°C 600
M22759/44/26-9 26 19/38 1.4 38.4 Silver Coated Copper Conductor 200°C 600
M22759/44-24-0 24 19/36 2 24.3 Silver Coated Copper Conductor 200°C 600
M22759/44-24-1 24 19/36 2 24.3 Silver Coated Copper Conductor 200°C 600
M22759/44-24-2 24 19/36 2 24.3 Silver Coated Copper Conductor 200°C 600
M22759/44-24-3 24 19/36 2 24.3 Silver Coated Copper Conductor 200°C 600
M22759/44-24-4 24 19/36 2 24.3 Silver Coated Copper Conductor 200°C 600
M22759/44-24-5 24 19/36 2 24.3 Silver Coated Copper Conductor 200°C 600
M22759/44-24-6 24 19/36 2 24.3 Silver Coated Copper Conductor 200°C 600
M22759/44-24-7 24 19/36 2 24.3 Silver Coated Copper Conductor 200°C 600
M22759/44-24-8 24 19/36 2 24.3 Silver Coated Copper Conductor 200°C 600
M22759/44-24-9 24 19/36 2 24.3 Silver Coated Copper Conductor 200°C 600
m22759/44-22-0 22 19/34 2.8 15.1 Silver Coated Copper Conductor 200°C 600
m22759/44-22-1 22 19/34 2.8 15.1 Silver Coated Copper Conductor 200°C 600
m22759/44-22-2 22 19/34 2.8 15.1 Silver Coated Copper Conductor 200°C 600
m22759/44-22-3 22 19/34 2.8 15.1 Silver Coated Copper Conductor 200°C 600
m22759/44-22-4 22 19/34 2.8 15.1 Silver Coated Copper Conductor 200°C 600
m22759/44-22-5 22 19/34 2.8 15.1 Silver Coated Copper Conductor 200°C 600
m22759/44-22-6 22 19/34 2.8 15.1 Silver Coated Copper Conductor 200°C 600
m22759/44-22-7 22 19/34 2.8 15.1 Silver Coated Copper Conductor 200°C 600
m22759/44-22-8 22 19/34 2.8 15.1 Silver Coated Copper Conductor 200°C 600
m22759/44-22-9 22 19/34 2.8 15.1 Silver Coated Copper Conductor 200°C 600
m22759/44-20-0 20 19/32 4.3 9.19 Silver Coated Copper Conductor 200°C 600
m22759/44-20-1 20 19/32 4.3 9.19 Silver Coated Copper Conductor 200°C 600
m22759/44-20-2 20 19/32 4.3 9.19 Silver Coated Copper Conductor 200°C 600
m22759/44-20-3 20 19/32 4.3 9.19 Silver Coated Copper Conductor 200°C 600
m22759/44-20-4 20 19/32 4.3 9.19 Silver Coated Copper Conductor 200°C 600
m22759/44-20-5 20 19/32 4.3 9.19 Silver Coated Copper Conductor 200°C 600
m22759/44-20-6 20 19/32 4.3 9.19 Silver Coated Copper Conductor 200°C 600
m22759/44-20-7 20 19/32 4.3 9.19 Silver Coated Copper Conductor 200°C 600
m22759/44-20-8 20 19/32 4.3 9.19 Silver Coated Copper Conductor 200°C 600
m22759/44-20-9 20 19/32 4.3 9.19 Silver Coated Copper Conductor 200°C 600
M22759/44-18-0 18 19/30 6.5 5.79 Silver Coated Copper Conductor 200°C 600
M22759/44-18-1 18 19/30 6.5 5.79 Silver Coated Copper Conductor 200°C 600
M22759/44-18-2 18 19/30 6.5 5.79 Silver Coated Copper Conductor 200°C 600
M22759/44-18-3 18 19/30 6.5 5.79 Silver Coated Copper Conductor 200°C 600
M22759/44-18-4 18 19/30 6.5 5.79 Silver Coated Copper Conductor 200°C 600
M22759/44-18-5 18 19/30 6.5 5.79 Silver Coated Copper Conductor 200°C 600
M22759/44-18-6 18 19/30 6.5 5.79 Silver Coated Copper Conductor 200°C 600
M22759/44-18-7 18 19/30 6.5 5.79 Silver Coated Copper Conductor 200°C 600
M22759/44-18-8 18 19/30 6.5 5.79 Silver Coated Copper Conductor 200°C 600
M22759/44-18-9 18 19/30 6.5 5.79 Silver Coated Copper Conductor 200°C 600
M22759/44-16-0 16 19/29 8.3 4.52 Silver Coated Copper Conductor 200°C 600
M22759/44-16-1 16 19/29 8.3 4.52 Silver Coated Copper Conductor 200°C 600
M22759/44-16-2 16 19/29 8.3 4.52 Silver Coated Copper Conductor 200°C 600
M22759/44-16-3 16 19/29 8.3 4.52 Silver Coated Copper Conductor 200°C 600
M22759/44-16-4 16 19/29 8.3 4.52 Silver Coated Copper Conductor 200°C 600
M22759/44-16-5 16 19/29 8.3 4.52 Silver Coated Copper Conductor 200°C 600
M22759/44-16-6 16 19/29 8.3 4.52 Silver Coated Copper Conductor 200°C 600
M22759/44-16-7 16 19/29 8.3 4.52 Silver Coated Copper Conductor 200°C 600
M22759/44-16-8 16 19/29 8.3 4.52 Silver Coated Copper Conductor 200°C 600
M22759/44-16-9 16 19/29 8.3 4.52 Silver Coated Copper Conductor 200°C 600
M22759/44-14-0 14 19/27 13 2.88 Silver Coated Copper Conductor 200°C 600
M22759/44-14-1 14 19/27 13 2.88 Silver Coated Copper Conductor 200°C 600
M22759/44-14-2 14 19/27 13 2.88 Silver Coated Copper Conductor 200°C 600
M22759/44-14-3 14 19/27 13 2.88 Silver Coated Copper Conductor 200°C 600
M22759/44-14-4 14 19/27 13 2.88 Silver Coated Copper Conductor 200°C 600
M22759/44-14-5 14 19/27 13 2.88 Silver Coated Copper Conductor 200°C 600
M22759/44-14-6 14 19/27 13 2.88 Silver Coated Copper Conductor 200°C 600
M22759/44-14-7 14 19/27 13 2.88 Silver Coated Copper Conductor 200°C 600
M22759/44-14-8 14 19/27 13 2.88 Silver Coated Copper Conductor 200°C 600
M22759/44-14-9 14 19/27 13 2.88 Silver Coated Copper Conductor 200°C 600
M22759/44-12-0 12 37/28 19.7 1.9 Silver Coated Copper Conductor 200°C 600
M22759/44-12-1 12 37/28 19.7 1.9 Silver Coated Copper Conductor 200°C 600
M22759/44-12-2 12 37/28 19.7 1.9 Silver Coated Copper Conductor 200°C 600
M22759/44-12-3 12 37/28 19.7 1.9 Silver Coated Copper Conductor 200°C 600
M22759/44-12-4 12 37/28 19.7 1.9 Silver Coated Copper Conductor 200°C 600
M22759/44-12-5 12 37/28 19.7 1.9 Silver Coated Copper Conductor 200°C 600
M22759/44-12-6 12 37/28 19.7 1.9 Silver Coated Copper Conductor 200°C 600
M22759/44-12-7 12 37/28 19.7 1.9 Silver Coated Copper Conductor 200°C 600
M22759/44-12-8 12 37/28 19.7 1.9 Silver Coated Copper Conductor 200°C 600
M22759/44-12-9 12 37/28 19.7 1.9 Silver Coated Copper Conductor 200°C 600

河南三博电子是一家专业MIL-W-22759/44 (M22759/44) | SAE AS22759/44的供应商，我公司经营MIL-W-22759/44 (M22759/44) | SAE AS22759/44产品多年，质量口碑可靠。如果您有更多的MIL-W-22759/44 (M22759/44) | SAE AS22759/44价格问题，欢迎您联系我们厂家
